Primary pancreatic hydatid cyst: a case report and literature review

BMC Gastroenterology volume 21, Article number: 164 (2021) Cite this article

Abstract

Background

Hydatid cysts are parasitic zoonoses that often occur in the liver. Pancreatic hydatid cysts are very rare and are usually misdiagnosed as pancreatic cystadenomas. At present, surgical resection combined with albendazole administration is the standard treatment for pancreatic hydatid cysts. However, making accurate preoperative diagnoses and avoiding intraoperative cystic rupture are challenges for surgeons.

Case presentation

A 28-year-old woman from the pastoral area presented to the surgical office complaining of abdominal pain and new-onset jaundice that began 9 days earlier. An enhanced computed tomography scan demonstrated a 6.0 × 5.3 cm pancreatic head cystic mass that compressed the common bile duct and induced choledochectasia. The preoperative diagnosis was pancreatic head cystadenoma, and laparotomic pancreaticoduodenectomy was initiated successfully. The intra- and postoperative diagnosis was pancreatic hydatid cyst. The patient was discharged uneventfully 7 days after the operation. A 1-year course of albendazole (15 mg/kg/day) was admitted.

Conclusion

Pancreatic hydatid cysts are rare and often misdiagnosed as other types of cysts. History of living in an area in which the causative organism is endemic and positive anti-echinococcus IgG antibody status could help with the diagnosis. Radical resection combined with oral albendazole administration is the standard treatment for pancreatic hydatid cysts. Avoiding perioperative cystic rupture and abdominal echinococcosis implantation metastasis is crucial for the success of the operation.

Peer Review reports

Background

Hydatid disease is a cosmopolitan zoonosis caused by the larvae of Echinococcus granulosus [1]. Hydatid disease is observed in the Northern Hemisphere, especially in China, the Russian Federation, continental European countries and North America [2]. Hydatid cysts often occur in the liver [3], and some extrahepatic organs including a rare form in the pancreas [4]. At present, some case reports of primary pancreatic hydatid cysts have been published [5,6,7]. However, the diagnosis is challenging due to its low morbidity, and the surgical procedure varies because of the different locations of the lesions and the understanding of this disease. In this article, we present a primary pancreatic hydatid disease case report and review published primary pancreatic hydatid cyst reports for better diagnosis and management.

Case presentation

Patient information

A 28-year-old woman presented to our department with body itching for more than ten days and jaundice for nine days. This patient had a long-term history of living in an area in which echinococcosis is endemic. Medical examination demonstrated yellow discoloration in both the skin and sclera, and abdominal examination was negative. After admission, the laboratory tests indicated a serum total bilirubin (Tbil) level of 264.0 μmol/L (5–22 μmol/L), conjugated bilirubin (Dbil) level of 205.6 μmol/L (0–7 μmol/L) and unconjugated bilirubin (Ibil) level of 58.4 μmol/L (0–20 μmol/L). Serum tumor markers, including carbohydrate antigen 19–9, α-fetoprotein and carcinoembryonic antigen, were not present. On the imaging examination, an emergency computed tomography (CT) scan indicated a 6.0 × 5.3 cm cystic lesion in the head of the pancreas adjacent to the lower bile duct and main pancreatic duct that induced expansion. There were no solid nodules or calcifications in this lesion, and a slightly higher lesion density with a curved mild calcification was observed at the edge of the cyst (Fig. 1). Magnetic resonance imaging (MRI) indicated the same signals at the center of the lesion and a high signal around the wall of the capsule, suggesting local diffusion limitation. MRCP imaging demonstrated that the bile duct and main pancreatic duct were clearly dilated, and the cyst communicated with the pancreatic bile duct (Fig. 2). Based on the preoperative examination, a diagnosis of pancreatic cystadenoma was made.

Fig. 1
figure 1

CT scans of the pancreatic hydatid cyst. a pancreatic cyst inducing bile duct and main pancreatic duct expanding; b pancreatic head hydatid cyst

Full size image
Fig. 2
figure 2

MRI of the pancreatic hydatid cyst. a The hydatid cyst mass (yellow arrow); b expanded main pancreatic duct (white arrow); c expanded bile duct (red arrow); d the hydatid cyst invaded the main pancreatic duct (blue arrow)

Full size image

Surgical procedure

During the laparotomy, a cyst lesion located in the pancreatic head was detected, which was adjacent to the duodenum and invaded the main pancreatic duct. After the cyst fluid was completely aspirated, the internal cyst collapsed and separated from what was previously considered the cyst wall (Fig. 3). The intraoperative pictures demonstrated signs of hydatid cysts (CE-1). The pancreaticoduodenectomy procedure was initiated successfully, and a “Child type” chongio-/gastric/pancreatic/jejunal anastomosis was performed. The patient was discharged uneventfully 7 days after the operation. A 1-year course of albendazole (15 mg/kg/day) was admitted and no recrudescence was detected in the postoperative 2 years. Pathological results indicated the presence of Echinococcosis granulosus accompanied by inflammatory cell infiltration and eosinophilic infiltration (Fig. 4).

Fig. 3
figure 3

The resected mass. The main pancreatic duct was invaded (white arrow)

Full size image
Fig. 4
figure 4

Pathological examination of the pancreatic hydatid cyst: a ×40; b ×200

Full size image

Literature review

A literature search was initiated to review primary pancreatic hydatid cysts. Based on our search results (Table 1), 22 papers in PubMed reported 33 cases of primary pancreatic hydatid cysts from 2011 to 2021 [8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,26,27,28,29]. In the 33 cases, 14 cases had cysts located in the pancreatic head, and 15 cases had lesions in the body/tail. Nineteen cases reported serum IgG levels, whereas the results of 8 cases were negative.

Table 1 Literature review of the primary pancreatic hydatid cyst in PubMed (2011–2021)
Full size table

Discussion and conclusion

Primary pancreatic hydatid cysts account for 0.14–2% of the total number of systemic echinococcoses [21]. Primary pancreatic hydatid cysts are caused by the Echinococcus granulosus hookworm entering the systemic circulation and traveling to the pancreas through two barriers, including the liver and lung. Primary pancreatic hydatid cysts often occur in the pancreatic head rather than body/tail because of richer blood supply for the pancreatic head [26]. However, there are 12 cases occurred in the pancreatic head and 12 cases occurred in the pancreatic body/tail in a total of 33 cases based on the literature review. The reason for the comparable occurring rate is the limited reviewed manuscripts.

There are no specific clinical signs when the cyst is located in the pancreatic body/tail, whereas obstructive jaundice may occur when the lesion is in the head of the pancreas, such as the presented case. Also, some cases may present acute pancreatitis firstly because of the main pancreatic duct obstruction [9, 12]. Because of its rare incidence, pancreatic hydatid cysts are often misdiagnosed as other cyst types, such as pancreatic cystadenoma or cystadenocarcinoma. For the cases with suspected pancreatic hydatid cysts, most had the characteristics of living in areas where echinococcosis is endemic and a history of close contact with sheep or dogs. These characteristics and imaging data should be combined to diagnose echinococcosis.

Enhancing CT scans, MRI and/or contrast-enhanced ultrasound examinations facilitate diagnosis. The characteristics of signals or multiple subcysts, calcifications and consolidation may be present in the resulting images. Kerimoglu et al. demonstrated that mild enhancement of the medial edge of the capsule wall might occur [30]. In our case, the image of the pancreatic tail shows a single capsule with a clear boundary. The cross-section image shows local nodular thickening of the cystic wall, and it is difficult to differentiate hydatid cysts from other cystic lesions of the pancreas. Also, contrast-enhanced ultrasound examinations may help for the identification because the contrast medium could enter the internal septations of cystadenoma or cystadenocarcinoma, whereas the cystic echinococcosis presented non-contrast medium entered in the sub-cysts, and the sub-cysts could move with the patient’s position changing [31]. Serum-positive anti-echinococcal IgG antibody status could help with the diagnosis, whereas which may be present due to the patient coming into contact with Echinococcus while living in an endemic area, rather than the assumed pancreatic hydatid cyst. In the reviewed literature, there are only 11 cases with positive anti-echinococcus IgG antibody in the 19 cases of confirmed pancreatic hydatid cyst.

Several surgical procedures have been described for the treatment of pancreatic hydatid cysts depending on their location [32]. Presently, available treatment options include radical resection, internal capsule stripping and external capsule removal (subadventitial total exocystectomy). In our case, the cyst was located in the pancreatic head, involved the main pancreatic duct and caused obstructive jaundice due to compression of the common bile duct; therefore, we performed pancreaticoduodenectomy. Based on the literature review, surgical drainage procedures have also been recommended but should not be the first selection because of the risk for abdominal intraperitoneal hydatid cyst implantation and metastasis. Additionally, cyst fluid overflow should be avoided during surgery.

In conclusion, pancreatic hydatidosis is a rare disease, and preoperative diagnosis of isolated pancreatic hydatid cysts in endemic regions is infrequent. It is difficult to differentiate between benign and malignant tumors of the pancreas before surgery. CT, MRI and/or contrast-enhanced ultrasound examination could be used to evaluate the malignant potential of the cyst and the presence of any connection with the main pancreatic duct. To clarify the relationship between cysts and the pancreatic duct, ERCP can be used to identify unknown cysts [33]. For cases strongly suspected to be pancreatic hydatids, preoperative evaluation should be combined with radiography and laboratory examination. A surgical procedure to prevent intra-abdominal spread with albendazole therapy thereafter may be an effective treatment for the disease.

Availability of data and materials

All data generated or analyzed during this study are included in this published article.

Abbreviations

Tbil:

Total bilirubin

Dbil:

Conjugated bilirubin

Ibil:

Unconjugated bilirubin

CT:

Computed tomography

MRI:

Magnetic resonance imaging

MRCP:

Magnetic Resonance Cholangiopancreatography

ERCP:

Endoscopic Retrograde Cholangio Pancreatography

References

  1. Agudelo Higuita NI, Brunetti E, McCloskey C. Cystic echinococcosis. J Clin Microbiol. 2016;54(3):518–23.

    Article  Google Scholar

  2. Deplazes P, Rinaldi L, Alvarez Rojas CA, Torgerson PR, Harandi MF, Romig T, et al. Global distribution of alveolar and cystic echinococcosis. Adv Parasitol. 2017;95:315–493.

    Article  CAS  Google Scholar

  3. Li Y, Ma Z, Tuxun T, Li Z, Meng Y, Chen X. The application of laparoscopy combined with indocyanine green fluorescence imaging technique for hepatic cystic echinococcosis. BMC Surg. 2020;20(1):249.

    Article  Google Scholar

  4. Seyed Reza M, Houman Khajouei K. Epigastric mass due to a hydatid cyst of the pancreas. A case report and review of the literature. JOP. 2007;8:232–4.

    Google Scholar

  5. Cağlayan K, Celik A, Koç A, Kutluk AC, Altinli E, Celik AS, Köksa N. Unusual locations of hydatid disease: diagnostic and surgical management of a case series. Surg Infect (Larchmt). 2010;11(4):349–53.

    Article  Google Scholar

  6. Malekzadeh R, Pezeshky B, Hormazdi M, Rakhshani N, Soroush Z. Primary hydatid disease of the pancreas. Arch Iran Med. 2006;9:291–2.

    PubMed  Google Scholar

  7. Chammakhi-Jemlinull W, Mekaouernull S, Miaouinull A, Daghfousnull A, Mzabinull H, Cherifnull A, et al. Hydatid cyst of the pancreas presenting with acute pancreatitis. J Radiol. 2010;91:797–9.

    Article  Google Scholar

  8. Sethi S, Puri SK, Agarwal A. Primary pancreatic hydatid: a rare cystic lesion of the pancreas. Am J Trop Med Hyg. 2017;96(4):763–4.

    Article  Google Scholar

  9. Suryawanshi P, Khan AQ, Jatal S. Primary hydatid cyst of pancreas with acute pancreatitis. Int J Surg Case Rep. 2011;2(6):122–4.

    Article  Google Scholar

  10. Agrawal S, Parag P. Hydatid cyst of head of pancreas mimicking choledochal cyst. BMJ Case Rep. 2011;2011:bcr0420114087.

    PubMed  PubMed Central  Google Scholar

  11. Hiremath B, Subramaniam N, Boggavarapu M. Primary pancreatic hydatid cyst: an unexpected differential diagnosis. BMJ Case Rep. 2015;2015:bcr2015211377.

    Article  Google Scholar

  12. Makni A, Jouini M, Kacem M, Safta ZB. Acute pancreatitis due to pancreatic hydatid cyst: a case report and review of the literature. World J Emerg Surg. 2012;7(1):7.

    Article  Google Scholar

  13. Trigui A, Rejab H, Guirat A, Mizouni A, Ben Amar M, Mzali R, et al. Hydatid cyst of the pancreas. About 12 cases. Ann Ital Chir. 2013;84:165–70.

    PubMed  Google Scholar

  14. Bakkaly AE, Merouane N, Dalero O, Oubeja H, Erraji M, Ettayebi F, et al. Primary hydatid cyst of the pancreas of the child: a case report. Pan Afr Med J. 2017;28(27):229.

    Google Scholar

  15. Elaffand A, Vijay A, Mohamed S, Al-Battah HH, Youssef A, Farahat A. Echinococcal cyst of the pancreas with cystopancreatic duct fistula successfully treated by partial cystectomy and cystogastrostomy. J Surg Tech Case Rep. 2015;7(2):48–50.

    Article  Google Scholar

  16. Varshney M, Shahid M, Maheshwari V, Siddiqui MA, Alam K, Mubeen A, et al. Hydatid cyst in tail of pancreas. BMJ Case Rep. 2011;2011:bcr0320114027.

    PubMed  PubMed Central  Google Scholar

  17. Yarlagadda P, Yenigalla BM, Penmethsa U, Myneni RB. Primary pancreatic echinococcosis. Trop Parasitol. 2013;3(2):151–4.

    Article  Google Scholar

  18. Tavusbay C, Gur OS, Durak E, Haciyanli M, Genc H. Hydatid cyst in abdominal incisional hernia. Bratisl Lek Listy. 2011;112:287–9.

    CAS  PubMed  Google Scholar

  19. Karaman B, Battal B, Ustunsoz B, Ugurel MS. Percutaneous treatment of a primary pancreatic hydatid cyst using a catheterization technique. Korean J Radiol. 2012;13(2):232–6.

    Article  Google Scholar

  20. Alsaid B, Alhimyar M, Rayya F. Pancreatic hydatid cyst causing acute pancreatitis: a case report and literature review. Case Rep Surg. 2018;5(2018):9821403.

    Google Scholar

  21. Ahmed Z, Chhabra S, Massey A, Vij V, Yadav R, Bugalia R, et al. Primary hydatid cyst of pancreas: case report and review of literature. Int J Surg Case Rep. 2016;27:74–7.

    Article  Google Scholar

  22. Mandelia A, Wahal A, Solanki S, Srinivas M, Bhatnagar V. Pancreatic hydatid cyst masquerading as a choledochal cyst. J Pediatr Surg. 2012;47(11):e41–4.

    Article  Google Scholar

  23. Deak J, Zadori G, Csiszko A, Damjanovich L, Szentkereszty Z. Hydatid disease of pancreas: a case report. Interv Med Appl Sci. 2019;11(1):74–6.

    PubMed  PubMed Central  Google Scholar

  24. Masoodi MI, Nabi G, Kumar R, Lone MA, Khan BA, Naseer Al Sayari K. Hydatid cyst of the pancreas: a case report and brief review. Turk J Gastroenterol. 2011;22(4):430–2.

    Article  Google Scholar

  25. Jonkov A, Todorov R, Katibova S. Clinical case of echinococcus of the pancreas. Khirurgiia (Sofiia). 2014;25:46–50.

    Google Scholar

  26. Lada PE, Termengo D, Caceres G, Sanchez Tacone C, Caballero F, Sonzini AP. Primary hydatid cyst of the pancreas. Rev Fac Cien Med Univ Nac Cordoba. 2017;74:33–6.

    PubMed  Google Scholar

  27. Vasilescu A, Tarcoveanu E, Crumpei F, Blaj M, Bejan V, Bradea C. Laparoscopic approach of primary hydatid cyst of the pancreas—case report and literature review. Chirurgia (Bucur). 2020;115(2):261–6.

    Article  Google Scholar

  28. Kisaoglu A, Ozogul B, Atamanalp SS, Pirimoglu B, Aydinli B, Korkut E. Incidental isolated pancreatic hydatid cyst. Turkiye Parazitol Derg. 2015;39(1):75–7.

    Article  Google Scholar

  29. Bhat NA, Rashid KA, Wani I, Wani S, Syeed A. Hydatid cyst of the pancreas mimicking choledochal cyst. Ann Saudi Med. 2011;31(5):536–8.

    Article  Google Scholar

  30. Kerimoglu U, Kapicioglu S, Emlik D, Arazi M, Ural O. Case 161: Hydatid disease with water lily sign manifesting as a soft-tissue mass in the calf of a child. Radiology. 2010;256(3):1007–10.

    Article  Google Scholar

  31. Yang C, Yang H, Deng S, Zhang Y. Hepatobiliary and Pancreatic: Hepatic cystadenoma mimics hepatic cystic echinococcsis. J Gastroenterol Hepatol. 2020;35(7):1098.

    Article  CAS  Google Scholar

  32. Dziri C, Dougaz W, Bouasker I. Surgery of the pancreatic cystic echinococcosis: systematic review. Transl Gastroenterol Hepatol. 2017;2:105.

    Article  Google Scholar

  33. Akbulut S, Yavuz R, Sogutcu N, Kaya B, Hatipoglu S, Senol A, et al. Hydatid cyst of the pancreas: report of an undiagnosed case of pancreatic hydatid cyst and brief literature review. World J Gastrointest Surg. 2014;6(10):190–200.

    Article  Google Scholar

Download references

Acknowledgements

The authors thank AJE for editing grammar, spelling, and other common errors.

Funding

None.

Author information

Author notes

  1. Yilei Wu and Jun Gong have contributed equally to this work

Authors and Affiliations

  1. Department of Medical Records Statistics, Sichuan Provincial People’s Hospital, University of Electronic Science and Technology of China, Chengdu, 611731, Sichuan, China

    Yilei Wu

  2. The Second Department of Hepatobiliary Surgery, Sichuan Provincial People’s Hospital, University of Electronic Science and Technology of China, Chengdu, 611731, Sichuan, China

    Jun Gong, Wei Xiong, Xiaojiong Yu & Xiangyu Lu

  3. Chinese Academy of Sciences Sichuan Translational Medicine Research Hospital, Chengdu, 610072, Sichuan, China

    Jun Gong, Wei Xiong, Xiaojiong Yu & Xiangyu Lu

Authors
  1. Yilei Wu
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Jun Gong
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Wei Xiong
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Xiaojiong Yu
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Xiangyu Lu
    View author publications

    You can also search for this author in PubMed Google Scholar

Contributions

XL and XY designed the study; JG, YW and WX collected the patient’s clinical data; XL and YW analyzed the data; XL wrote the paper. All authors read and approved the final manuscript.

Corresponding authors

Correspondence to Xiaojiong Yu or Xiangyu Lu.

Ethics declarations

Ethics approval and consent to participate

An approval from the hospital board committee is taken for the procedure and case report publication.

Consent for publication

Written informed consent for publication was obtained from the participant. There aren’t any personal or clinical details along with the images to be published in this study.

Competing interests

The authors declared no conflict of interest.
